4G/5G Products
Explore our range of 4g/5g products designed for industrial IoT applications with reliability and performance in mind.
Technical Specifications
| Cellular Bands | B1/B3/B5/B8 (FDD LTE); B34/B38/B39/B40/B41 (TDD LTE); B3/B8 (GSM) |
| Throughput | LTE ↓10 Mbps / ↑5 Mbps; GPRS ↓85.6 kbps / ↑85.6 kbps |
| Serial Interfaces | RS-232 (DB9) & RS-485 (3.5 mm terminal) |
| Serial Parameters | 300–460 800 bps; 5–8 data bits; None/Odd/Even parity; 1–2 stop bits; hardware/software flow control |
| Buffer Storage | Dozens of MB (~50 MB) offline logs |
| SIM & Antenna | Standard SIM (3 V / 1.8 V); 50 Ω SMA female antenna port (stick or suction-cup) |
Technical Specifications
| Serial Interface | 1 x RS-485 |
| Network Interface | 4G, Optional(WiFi/Ethernet) |
| Network Speed | DL 110 Mbps / UL 15 Mbps |
| Protocols | MQTT (JSON), HTTP GET/POST, Modbus RTU TCP, TCP/UDP |
| Input Channels | 4 x DI (Dry/Wet) + 4 x AI (4-20mA/0-10V) |
| Power Supply | 9-24V DC (Terminal Block) |
Technical Specifications
| Serial Interface | 1 x RS-485 |
| Network Interface | 4G LTE Cat 1 (B1/B3/B5/B8) |
| Network Speed | DL 10 Mbps / UL 5 Mbps |
| Protocols | Modbus TCP/RTU, MQTT, JSON, HTTP, Optional(MQTTS) |
| Power Supply | 9-24V DC (Reverse-polarity protection) |
| Operating Temperature | -40°C to +85°C |
Technical Specifications
| Serial Interface | 1 x RS-232 + 1 x RS-485 |
| Network Interface | 4G/Ethernet |
| Network Speed | LTE Cat 4 (DL 150 Mbps) |
| Protocols | Transparent, Modbus Gateway, VPN, TCP/UDP |
| Power Supply | 9-24V DC |
| Storage | Upto 50MB |
Technical Specifications
| Serial Interface | 1 x RS-232/485 (DB9 or Terminal) |
| Network Interface | 4G LTE (FDD/TDD) with GSM Fallback |
| Network Speed | LTE Cat 1: 10Mbps DL / 5Mbps UL |
| Protocols | TCP Server/Client, UDP, Virtual COM, MQTT, HTTP |
| Power Supply | 9-24V DC via Terminal Block |
| Operating Temperature | -40°C to +85°C |
